Everything you need to know about specifications and performance - Hyundai i30 2013 - 1.6 GDI (135 Hp)

Full specifications and technical details 2013 Hyundai i30 II Coupe 1.6 GDI (135 Hp)

Overview:

What is the engine capacity of a Hyundai i30 2013?
The engine capacity of the Hyundai i30 2013 is 1591.

Hyundai i30 2013 How many horsepower?
The engine power of the Hyundai i30 2013 is 135 Hp @ 6300 rpm..

What is the Hyundai i30 2013 engine?
Hyundai i30 2013 engine is G4FD. (Click to see other cars using the same engine)

How much gasoline does a Hyundai i30 2013 consume?
The Hyundai i30 2013 consumes 6 liters of gasoline per 100 km

What is the recommended oil for a Hyundai i30 2013 engine?
The recommended oil for a Hyundai i30 2013 car engine is 0W-30, 5W-30.

What type of camshaft transmission system is used in a Hyundai i30 2013 engine?
chain is used to transmit motion.

General:

Brand: Hyundai

Model: i30

Generation: II Coupe

Modification (Engine): 1.6 GDI (135 Hp)

Start of production: 2013

End of production: 2015

Powertrain Architecture: Internal Combustion Engine

Body type:Coupe

Seats: 5

Doors: 3

Engine:

Power: 135 hp @ 6300 rpm.

Power per litre: 84.9 hp/l

Torque: 164 nm @ 4850 rpm.

Engine Model/Code:G4FD

Engine displacement: 1591

Number of cylinders: 4

Engine configuration: Inline

Number of valves per cylinder: 4

Fuel injection system: Direct injection

Engine aspiration: Naturally aspirated Engine

Valvetrain: DOHC

Engine oil capacity: 3.6 l

Coolant: 5.8 l

Engine layout: Front, Transverse

Cylinder Bore: 77 mm

Piston Stroke: 85.44 mm

Compression ratio: 11:1

recommended engine oil: 0W-30, 5W-30

euro standards: EURO 5/6

engine lifespan (km): ~300 000

weight (kg): 101.9

timing drive: chain

Show more details about this engine

Performance:

Fuel Type: Petrol (Gasoline)

Fuel consumption (economy) - urban: 8 l/100 km

Fuel consumption (economy) - extra urban: 4.7 l/100 km

Fuel consumption (economy) - combined: 6 l/100 km

Emission standard: Euro 5

Acceleration 0 - 100 km/h: 9.9 sec

Acceleration 0 - 62 mph: 9.9 sec

Maximum speed: 195 km/h

Weight-to-power ratio: 8.8 kg/Hp, 113.3 Hp/tonne

Weight-to-torque ratio: 7.3 kg/Nm, 137.6 Nm/tonne

Acceleration 0 - 60 mph: 9.4 sec

Space:

Kerb Weight (kg): 1192

Max. weight (kg): 1820

Max load (kg): 628

Trunk (boot) space - maximum: 1316 l

Trunk (boot) space - minimum: 378 l

Fuel tank capacity: 53 l

dimensions:

Length: 4300 mm

Width: 1780 mm

Height: 1470 mm

wheelbase: 2650 mm

Front track: 1555 mm

Rear (Back) track: 1563 mm

Ride height (ground clearance): 140 mm

Minimum turning circle (turning diameter): 10.6 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.

Drive wheel: Front wheel drive

Number of gears and type of gearbox: 6 gears, manual transmission

Front brakes: Ventilated discs

Rear brakes: Disc

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Tires size: 205/55 R16 H

Wheel rims size: 16

Front suspension: Independent type McPherson

Rear suspension: Independent multi-link Spring suspension with stabilizer
