Fiat Multipla 186, facelift 2004 1.9 MultiJet (120 Hp) DPF
Fiat Multipla:
The Fiat Multipla is a six-seater car produced by Italian automaker Fiat from 1998 to 2010. Based on the Bravo/Brava, the Multipla was shorter and wider than its rivals. It had two rows of three seats, where its compact MPV competitors had two across front seating. The Multipla is shorter than the three-door Bravo/Brava on which it was based, yet it offered increased seating and cargo volume. Sales commenced in Italy in November 1998.
In common with a number of other modern Fiats, the Multipla reused the name of an earlier vehicle, in this case the "Multipla" variant of the Fiat 600 produced during the 1950s and 1960s....(Read more on Wikipedia)
186, facelift 2004 Overview:
Fiat Multipla (186, facelift 2004). With 210 Nm of torque, it offers ample pulling power. It has moderate fuel consumption (~8.2 l/100km). With a weight of 1370 kg, it falls in the mid‑range. Front‑wheel drive delivers efficiency and easy handling. The top speed reaches 179 km/h. A multi-purpose vehicle designed to transport passengers with ample interior space. With seating for 6, it’s perfect for larger families.
Pros and Cons:
Pros:
- • Efficiency-focused engine (120 hp), ideal for city commuting.
- • Balanced fuel consumption of 6.5 L/100 km for its class.
- • Ventilated disc brakes for reliable cooling and stopping power.
- • Standard trunk space (430 L) suitable for daily needs.
- • Turbocharged engine ensures better torque delivery at low RPMs.
Cons:
- • Meets EURO 4 emission standard; check for local urban restriction zones.
- • Previous generation model; may lack the latest driver-assist technologies.
Specifications:
Specifications are compared to those of the previous generation(186, facelift 2004: 2004 - 2010).
| General: |
| Brand: | Fiat |
|---|
| Model: | Multipla |
|---|
| Generation: | 186, facelift 2004 |
|---|
| Modification (Engine): | 1.9 MultiJet (120 Hp) DPF |
|---|
| Start of production: | 2006 |
|---|
| End of production: | 2010 |
|---|
| Powertrain Architecture: | Internal Combustion engine |
|---|
| Body type: | MPV |
|---|
| Seats: | 6 |
|---|
| Doors: | 5 |
|---|
| Engine: |
| Engine systems: | Particulate filter |
|---|
| Power: | 120 Hp @ 4000 rpm. Same horsepower |
|---|
| Power per litre: | 62.8 Hp/l [Same length.] |
|---|
| Torque: | 210 Nm @ 3000 rpm. |
|---|
| Engine Model/Code: | 186A9000 More details about the engine 186A9000 |
|---|
| Engine displacement: | 1910 |
|---|
| Number of cylinders: | 4 |
|---|
| Engine configuration: | Inline |
|---|
| Number of valves per cylinder: | 4 |
|---|
| Fuel injection system: | Diesel Commonrail |
|---|
| Engine aspiration: | Turbocharger, Intercooler |
|---|
| Valvetrain: | SOHC |
|---|
| Engine oil capacity: | 4.5 l |
|---|
| Coolant: | 6.3 l |
|---|
| Engine layout: | Front, Transverse |
|---|
| Cylinder Bore: | 82 mm mm |
|---|
| Piston Stroke: | 90.4 mm mm |
|---|
| Compression ratio: | 18:1 |
|---|
| Performance: |
| Fuel Type: | Diesel |
|---|
| Fuel consumption (economy) - urban: | 8.2 l/100 km |
|---|
| Fuel consumption (economy) - extra urban: | 5.6 l/100 km |
|---|
| Fuel consumption (economy) - combined: | 6.5 l/100 km |
|---|
| Emission standard: | Euro 4 |
|---|
| Maximum speed: | 179 km/h |
|---|
| Weight-to-power ratio: | 11.4 kg/Hp, 87.6 Hp/tonne |
|---|
| Weight-to-torque ratio: | 6.5 kg/Nm, 153.3 Nm/tonne |
|---|
| Space: |
| Kerb Weight: | 1370 |
|---|
| Trunk (boot) space - maximum: | 1900 l |
|---|
| Trunk (boot) space - minimum: | 430 l |
|---|
| Permitted trailer load with brakes (12%): | 1300 kg |
|---|
| Fuel tank capacity: | 63 l |
|---|
| Permitted trailer load without brakes: | 560 kg |
|---|
| Size: |
| Length: | 4090 mm mm [Same length.] |
|---|
| Width: | 1870 mm mm [Same width.] |
|---|
| Height: | 1690 mm mm [Same height.] |
|---|
| Wheelbase: | 2666 mm mm [Same wheelbase.] |
|---|
| Front track: | 1515 mm |
|---|
| Rear (Back) track: | 1520 mm |
|---|
| Front overhang: | 837 mm |
|---|
| Rear overhang: | 586 mm |
|---|
| Minimum turning circle (turning diameter): | 11 m [above average] |
|---|
| Powertrain: |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of gears | 5 |
|---|
| Transmission type | Manual |
|---|
| Front brakes | Ventilated discs, 284 mm [Best for performance and cooling.] |
|---|
| Rear brakes | Drum, 228 mm [bad for performance and cooling.] |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 185/65 R15 |
|---|
| Wheel rims size | 15 |
|---|
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
|---|
| Rear suspension | Leaf spring |
|---|
