Everything you need to know about specifications and performance - Ford Mondeo 1993 - 1.8 TD (88 Hp)
Overview:
What is the engine capacity of a Ford Mondeo 1993?
The engine capacity of the Ford Mondeo 1993 is 1753.
Ford Mondeo 1993 How many horsepower?
The engine power of the Ford Mondeo 1993 is 88 Hp @ 4500 rpm..
What is the Ford Mondeo 1993 engine?
Ford Mondeo 1993 engine is RFM, RFN. (Click to see other cars using the same engine)
How much gasoline does a Ford Mondeo 1993 consume?
The Ford Mondeo 1993 consumes 6.1 liters of gasoline per 100 km
General:
Engine:
Power: 88 hp @ 4500 rpm.
Power per litre: 50.2 hp/l
Torque: 178 nm @ 2200 rpm.
Engine Model/Code:RFM, RFN
Engine displacement: 1753
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 2
Fuel injection system: Precombustion chamber injection
Engine aspiration: Turbocharger
Valvetrain: OHC
Engine oil capacity: 5.1 l
Coolant: 9.5 l
Engine layout: Front, Transverse
Cylinder Bore: 82.5 mm
Piston Stroke: 82 mm
Compression ratio: 21.5:1
Performance:
Fuel Type: Diesel
Fuel consumption (economy) - urban: 7.4 l/100 km
Fuel consumption (economy) - extra urban: 4.3 l/100 km
Fuel consumption (economy) - combined: 6.1 l/100 km
Acceleration 0 - 100 km/h: 13.5 sec
Acceleration 0 - 62 mph: 13.5 sec
Maximum speed: 183 km/h
Weight-to-power ratio: 14.6 kg/Hp, 68.5 Hp/tonne
Weight-to-torque ratio: 7.2 kg/Nm, 138.5 Nm/tonne
Acceleration 0 - 60 mph: 12.8 sec
Space:
Kerb Weight (kg): 1285
Max. weight (kg): 1800
Max load (kg): 515
Trunk (boot) space - minimum: 480 l
Fuel tank capacity: 61 l
dimensions:
Length: 4480 mm
Width: 1750 mm
Height: 1430 mm
wheelbase: 2705 mm
Front track: 1505 mm
Rear (Back) track: 1485 mm
Powertrain, Suspension and Brakes:
Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 5 gears, manual transmission
Front brakes: Disc
Rear brakes: Drum
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Hydraulic Steering
Tires size: 185/65 R14
Wheel rims size: 6J x 14
Front suspension: Wishbone
Rear suspension: Coil Spring
