Hyundai Grandeur/Azera Grandeur III (XG, facelift 2003) 2.5i V6 (172 Hp) Automatic
Overall Rating
Hyundai Grandeur/Azera:
The Hyundai Grandeur is a executive sedan manufactured and marketed by the South Korean manufacturer Hyundai since 1986, over seven generations.
From 1986 to 1996, the Grandeur was the flagship for Hyundai's South Korean range before the Hyundai Dynasty was introduced. It is marketed globally as the Hyundai Azera. As the Azera, it was the flagship of Hyundai's US and Canadian lineup until the arrival of the Genesis sedan. After the launch of the separate Genesis brand, the Grandeur/Azera resumed its place as the company's flagship....(Read more on Wikipedia)
Grandeur III (XG, facelift 2003) Overview:
Hyundai Grandeur/Azera (Grandeur III (XG, facelift 2003)). With 225 Nm of torque, it offers ample pulling power. With a weight of 1557 kg, it falls in the mid‑range. Front‑wheel drive delivers efficiency and easy handling. The top speed reaches 205 km/h. A four-door car with a separate trunk, ideal for families and daily commuting. Seating for 5 makes it ideal for daily use.
2.5i V6 (172 Hp) Automatic Verdict:
Performance Verdict
The 2.5L V6 offers a more suitable power output for the Grandeur, providing smoother acceleration and more confident overtaking, striking a better balance for daily driving.
Fuel Economy
Fuel economy remains average for its class, slightly worse than the 2.0L due to increased displacement but offering better performance per liter, making it a reasonable compromise.
Pros and Cons:
Pros:
- • Smooth and refined V6 engine options (especially 2.5L and above)
- • Spacious and comfortable interior with good ride quality
- • Good value for money in the executive sedan segment
- • Generally reliable powertrain for its era
- • Quiet cabin, ideal for long journeys
Cons:
- • Underpowered base 2.0L V6 for its size and weight
- • Mediocre fuel economy across the entire V6 range
- • Soft suspension leads to less dynamic or engaging handling
- • Interior design can feel dated compared to some European rivals
- • Lack of official Euro NCAP safety rating
Specifications:
Specifications are compared to those of the previous generation(Grandeur III (XG): 1999 - 2002).
| General: | |
|---|---|
| Brand: | Hyundai |
| Model: | Grandeur/Azera |
| Generation: | Grandeur III (XG, facelift 2003) |
| Modification (Engine): | 2.5i V6 (172 Hp) Automatic |
| Start of production: | 2003 |
| End of production: | 2005 |
| Powertrain Architecture: | Internal Combustion engine |
| Body type: | Sedan |
| Seats: | 5 |
| Doors: | 4 |
| Engine: | |
|---|---|
| Power: | 172 Hp @ 6250 rpm. |
| Power per litre: | 69 Hp/l |
| Torque: | 225 Nm @ 4000 rpm. |
| Engine Model/Code: | Delta / G6BV [Same engine] More details about the engine Delta / G6BV |
| Engine displacement: | 2494 |
| Number of cylinders: | 6 |
| Engine configuration: | V-engine |
| Number of valves per cylinder: | 4 |
| Fuel injection system: | Multi-port manifold injection |
| Engine aspiration: | Naturally aspirated engine |
| Valvetrain: | DOHC |
| Engine oil capacity: | 4.5 l |
| Coolant: | 9.5 l |
| Engine layout: | Front, Transverse |
| Cylinder Bore: | 84 mm |
| Piston Stroke: | 75 mm |
| Compression ratio: | 10:1 |
| Performance: | |
|---|---|
| Fuel Type: | Petrol (Gasoline) |
| Maximum speed: | 205 km/h |
| Weight-to-power ratio: | 9.1 kg/Hp, 110.5 Hp/tonne |
| Weight-to-torque ratio: | 6.9 kg/Nm, 144.5 Nm/tonne |
| Space: | |
|---|---|
| Kerb Weight: | 1557 |
| Trunk (boot) space - minimum: | 410 l |
| Fuel tank capacity: | 70 l |
| Size: | |
|---|---|
| Length: | 4875 mm [10mm more] |
| Width: | 1800 mm [25mm less] |
| Height: | 1420 mm [Same height.] |
| Wheelbase: | 2750 mm [Same wheelbase.] |
| Front track: | 1540 mm |
| Rear (Back) track: | 1520 mm |
| Ride height (ground clearance): | 160 mm |
| Minimum turning circle (turning diameter): | 12.6 m [above average] |
| Powertrain: | |
|---|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears | 4 |
| Transmission type | Automatic |
| Front brakes | Ventilated discs [Best for performance and cooling.] |
| Rear brakes | Disc [above average] |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 205/60 R16 H |
| Wheel rims size | 16 |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link suspension |
