Everything you need to know about specifications and performance - Hyundai i30 2016 - 1.4 MPi (100 Hp)

Full specifications and technical details 2016 Hyundai i30 III 1.4 MPi (100 Hp)

Overview:

What is the engine capacity of a Hyundai i30 2016?
The engine capacity of the Hyundai i30 2016 is 1368.

Hyundai i30 2016 How many horsepower?
The engine power of the Hyundai i30 2016 is 100 Hp @ 6000 rpm..

What is the Hyundai i30 2016 engine?
Hyundai i30 2016 engine is Kappa / G4LC. (Click to see other cars using the same engine)

General:

Brand: Hyundai
Model: i30
Generation: III
Modification (Engine): 1.4 MPi (100 Hp)
Start of production: 2016
End of production: 2018
Powertrain Architecture: Internal Combustion Engine
Body type:Hatchback
Seats: 5
Doors: 5

Engine:

Power: 100 hp @ 6000 rpm.
Power per litre: 73.1 hp/l
Torque: 134 nm @ 4000 rpm.
Engine Model/Code:Kappa / G4LC
Engine displacement: 1368
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 4
Fuel injection system: Multi-port manifold injection
Engine aspiration: Naturally aspirated Engine
Valvetrain: DOHC
Engine oil capacity: 3.6 l
Coolant: 5.8 l
Engine layout: Front, Transverse
Cylinder Bore: 72 mm
Piston Stroke: 84 mm
Compression ratio: 10.5:1

Performance:

Fuel Type: Petrol (Gasoline)
Acceleration 0 - 100 km/h: 12.7 sec
Acceleration 0 - 62 mph: 12.7 sec
Maximum speed: 183 km/h
Weight-to-power ratio: 11.7 kg/Hp, 85.5 Hp/tonne
Weight-to-torque ratio: 8.7 kg/Nm, 114.6 Nm/tonne
Acceleration 0 - 60 mph: 12.1 sec

Space:

Kerb Weight (kg): 1169-1316
Max. weight (kg): 1760
Max load (kg): 444-591
Trunk (boot) space - maximum: 1301 l
Trunk (boot) space - minimum: 395 l
Fuel tank capacity: 50 l

dimensions:

Length: 4340 mm
Width: 1795 mm
Height: 1455 mm
wheelbase: 2650 mm
Front overhang: 905 mm
Rear overhang: 785 mm
Ride height (ground clearance): 140 mm
Minimum turning circle (turning diameter): 10.6 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 6 gears, manual transmission
Front brakes: Ventilated discs
Rear brakes: Disc
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Electric Steering
Tires size: 195/65 R15; 205/55 R16; 225/45 R17
Wheel rims size: 6.0J x 15; 6.5J x 16; 7.0J x 17
Front suspension: Independent type McPherson
Rear suspension: Independent multi-link suspension
