Everything you need to know about specifications and performance - Peugeot Partner 2017 - 22.5 kWh (67 Hp) Electric
Overview:
How powerful is the electrical system in the Peugeot Partner 2017?
The power of the electrical system in the Peugeot Partner 2017 is 67 Hp @ 4000-9200 rpm. hp.
General:
Brand: Peugeot
Model: Partner
Generation: II Tepee (Phase III, 2015)
Modification (Engine): 22.5 kWh (67 Hp) Electric
Start of production: 2017
End of production: 2018
Powertrain Architecture: BEV (Electric Vehicle)
Body type:Mini van
Seats: 5
Doors: 5
Engine:
Performance:
Fuel Type: Electricity
Acceleration 0 - 100 km/h: 19.5 sec
Acceleration 0 - 62 mph: 19.5 sec
Maximum speed: 110 km/h
Weight-to-power ratio: 26.8 kg/Hp, 37.3 Hp/tonne
Weight-to-torque ratio: 9 kg/Nm, 111.5 Nm/tonne
Acceleration 0 - 60 mph: 18.5 sec
Electric system:
Net (usable) battery capacity: 20.5 kWh
Gross battery capacity: 22.5 kWh
Battery technology: Lithium-ion (Li-Ion)
Battery location: Under the rear seats
System power: 67 hp @ 4000-9200 rpm.
System torque: 200 nm @ 0-1500 rpm.
All-electric range: 170 km
Electric motor power: 67 hp @ 4000-9200 rpm.
Electric motor Torque: 200 nm @ 0-1500 rpm.
Average Energy consumption: 17.7 kWh/100 km
Electric motor location: Front axle, Transverse
Battery voltage: 300 V
Average Energy consumption (NEDC): 17.7 kWh/100 km
All-electric range (NEDC): 170 km
Space:
Kerb Weight (kg): 1794
Max. weight (kg): 2175
Max load (kg): 381
Trunk (boot) space - maximum: 3000 l
Trunk (boot) space - minimum: 544 l
dimensions:
Length: 4380 mm
Width: 1810 mm
Height: 1883 mm
wheelbase: 2728 mm
Width including mirrors: 2112 mm
Front track: 1505 mm
Rear (Back) track: 1554 mm
Front overhang: 925 mm
Rear overhang: 727 mm
Ride height (ground clearance): 144 mm
Minimum turning circle (turning diameter): 11.5 m
Powertrain, Suspension and Brakes:
Drivetrain Architecture: One electric motor drives the front wheels.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 1 gears, automatic transmission
Front brakes: Ventilated discs
Rear brakes: Disc
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Tires size: 195/70 R15
Wheel rims size: 15
Front suspension: Independent type McPherson
Rear suspension: Torsion
