Everything you need to know about specifications and performance - RAM 2500/3500 2014 - 2500 6.4 Hemi V8 (410 Hp) Automatic
Overview:
What is the engine capacity of a RAM 2500/3500 2014?
The engine capacity of the RAM 2500/3500 2014 is 6417.
RAM 2500/3500 2014 How many horsepower?
The engine power of the RAM 2500/3500 2014 is 410 Hp @ 5600 rpm..
What is the RAM 2500/3500 2014 engine?
RAM 2500/3500 2014 engine is ESA. (Click to see other cars using the same engine)
General:
Brand: RAM
Model: 2500/3500
Generation: Crew Cab I (facelift 2013)
Modification (Engine): 2500 6.4 Hemi V8 (410 Hp) Automatic
Start of production: 2014
End of production: 2018
Powertrain Architecture: Internal Combustion Engine
Body type:Pickup
Seats: 5-6
Doors: 4
Engine:
Power: 410 hp @ 5600 rpm.
Power per litre: 63.9 hp/l
Torque: 582 nm @ 4000 rpm.
Engine Model/Code:ESA
Engine displacement: 6417
Number of cylinders: 8
Engine configuration: V-engine
Number of valves per cylinder: 2
Fuel injection system: Multi-port manifold injection
Engine aspiration: Naturally aspirated Engine
Valvetrain: OHV
Engine oil capacity: 6.6 l
Coolant: 15.7 l
Engine layout: Front, Longitudinal
Cylinder Bore: 103.9 mm
Piston Stroke: 94.6 mm
Compression ratio: 10:1
Maximum engine speed: 5800 rpm.
Performance:
Fuel Type: Petrol (Gasoline)
Weight-to-power ratio: 7.6 kg/Hp, 131.8 Hp/tonne
Weight-to-torque ratio: 5.3 kg/Nm, 187.1 Nm/tonne
Space:
Kerb Weight (kg): 3110
Max. weight (kg): 4536
Max load (kg): 1426
Trunk (boot) space - maximum: 1628 l
Permitted trailer load with brakes (12%): 5656 kg
Fuel tank capacity: 117 l
dimensions:
Ramp-over (brakeover) angle: 15.1°
Length: 6030 mm
Width: 2009 mm
Height: 1872 mm
wheelbase: 3795 mm
Width including mirrors: 2009 mm
Front track: 1742 mm
Rear (Back) track: 1732 mm
Minimum turning circle (turning diameter): 14.4 m
Approach angle: 13.4°
Departure angle: 18.8°
Powertrain, Suspension and Brakes:
Drivetrain Architecture: The Internal combustion Engine (ICE) drives the rear wheels of the vehicle.
Drive wheel: Rear wheel drive
Number of gears and type of gearbox: 6 gears, automatic transmission
Front brakes: Disc
Rear brakes: Disc
Assisting systems: ABS (Anti-lock braking system)
Power steering: Hydraulic Steering
Tires size: 275/70 R18 118T; 285/60 R20 115H
Wheel rims size: 8J x 18 ET43; 8J x 20 ET55
Front suspension: Independent multi-link suspension
Rear suspension: Independent multi-link suspension
