Everything you need to know about specifications and performance - Toyota Ractis I 2005 - 1.5i 16V (110 Hp)

Full specifications and technical details 2005 Toyota Ractis I 1.5i 16V (110 Hp)

Overview:

What is the engine capacity of a Toyota Ractis 2005?
The engine capacity of the Toyota Ractis 2005 is 1496.

Toyota Ractis 2005 How many horsepower?
The engine power of the Toyota Ractis 2005 is 110 Hp @ 6000 rpm..

What is the Toyota Ractis 2005 engine?
Toyota Ractis 2005 engine is 1NZ-FE. (Click to see other cars using the same engine)

What is the recommended oil for a Toyota Ractis 2005 engine?
The recommended oil for a Toyota Ractis 2005 car engine is 5W-30 (Toyota manual: 5W-30; summer option 10W-30).

What type of camshaft transmission system is used in a Toyota Ractis 2005 engine?
Timing chain is used to transmit motion.

General:

Brand: Toyota

Model: Ractis

Generation: I

Modification (Engine): 1.5i 16V (110 Hp)

Start of production: October, 2005

End of production: November, 2010

Powertrain Architecture: Internal Combustion Engine

Body type:Mini van

Seats: 5

Doors: 5

Engine:

Power: 110 hp @ 6000 rpm.

Power per litre: 73.5 hp/l

Torque: 141 nm @ 4400 rpm.

Engine Model/Code:1NZ-FE

Engine displacement: 1496

Number of cylinders: 4

Engine configuration: Inline

Number of valves per cylinder: 4

Fuel injection system: Multi-port manifold injection

Engine aspiration: Naturally aspirated Engine

Valvetrain: DOHC

Engine oil capacity: 3.7 l

Coolant: 4.7 l

Engine layout: Front, Transverse

Cylinder Bore: 75 mm

Piston Stroke: 84.7 mm

Compression ratio: 10.5:1

recommended engine oil: 5W-30 (Toyota manual: 5W-30; summer option 10W-30)

oil change interval: 5000–10000 km

amount of engine oil for replacement: 3.4 l

weight (kg): 87 kg

timing drive: timing chain

Show more details about this engine

Performance:

Fuel Type: Petrol (Gasoline)

Fuel consumption (economy) - extra urban: 5.5 l/100 km

Emission standard: Euro 4

Weight-to-power ratio: 10.4 kg/Hp, 96.5 Hp/tonne

Weight-to-torque ratio: 8.1 kg/Nm, 123.7 Nm/tonne

Space:

Kerb Weight (kg): 1140

Max. weight (kg): 1415

Max load (kg): 275

dimensions:

Length: 3995 mm

Width: 1695 mm

Height: 1640 mm

wheelbase: 2550 mm

Front track: 1485 mm

Rear (Back) track: 1475 mm

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.

Drive wheel: Front wheel drive

Front brakes: Ventilated discs

Rear brakes: Drum

Assisting systems: ABS (Anti-lock braking system)

Front suspension: Independent type McPherson

Rear suspension: Torsion
