Everything you need to know about specifications and performance - Volkswagen Caddy 2009 - 2.0 EcoFuel (109 Hp) CNG

Overview:
What is the engine capacity of a Volkswagen Caddy 2009?
The engine capacity of the Volkswagen Caddy 2009 is 1984.
Volkswagen Caddy 2009 How many horsepower?
The engine power of the Volkswagen Caddy 2009 is 109 Hp @ 5400 rpm..
What is the Volkswagen Caddy 2009 engine?
Volkswagen Caddy 2009 engine is EA113 / BSX. (Click to see other cars using the same engine)
How much gasoline does a Volkswagen Caddy 2009 consume?
The Volkswagen Caddy 2009 consumes 5.9 kg/100 km liters of gasoline per 100 km
General:
Brand: Volkswagen
Model: Caddy
Generation: Maxi III
Modification (Engine): 2.0 EcoFuel (109 Hp) CNG
Start of production: 2009
End of production: 2010
Powertrain Architecture: Internal Combustion Engine
Body type:Mini van
Seats: 7
Doors: 4-5
Engine:
Power: 109 hp @ 5400 rpm.
Power per litre: 54.9 hp/l
Torque: 160 nm @ 3500 rpm.
Engine Model/Code:EA113 / BSX
Engine displacement: 1984
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 2
Fuel injection system: Multi-port manifold injection
Engine aspiration: Naturally aspirated Engine
Valvetrain: SOHC
Engine oil capacity: 4 l
Coolant: 8 l
Engine layout: Front, Transverse
Cylinder Bore: 82.5 mm
Piston Stroke: 92.8 mm
Compression ratio: 13.5:1
Performance:
Fuel Type: Petrol / CNG
Fuel consumption (economy) - urban: 8.1 kg/100 km
Fuel consumption (economy) - extra urban: 4.6 kg/100 km
Fuel consumption (economy) - urban (CNG): 8.1 kg/100 km
Fuel consumption (economy) - extra urban (CNG): 4.6 kg/100 km
Fuel consumption (economy) - combined (CNG): 5.9 kg/100 km
Fuel consumption (economy) - combined: 5.9 kg/100 km
Emission standard: Euro 5
Acceleration 0 - 100 km/h: 14.8 sec
Acceleration 0 - 62 mph: 14.8 sec
Maximum speed: 169 km/h
Weight-to-power ratio: 16.1 kg/Hp, 62.3 Hp/tonne
Weight-to-torque ratio: 10.9 kg/Nm, 91.4 Nm/tonne
Acceleration 0 - 60 mph: 14.1 sec
Space:
Kerb Weight (kg): 1751-1850
Max. weight (kg): 2375
Max. roof load: 100 kg
Max load (kg): 525-624
Trunk (boot) space - maximum: 3950 l
Trunk (boot) space - minimum: 530 l
Fuel tank capacity: 13 l
CNG cylinder capacity: 37 kg
dimensions:
Length: 4875 mm
Width: 1794 mm
Height: 1834 mm
wheelbase: 3002 mm
Width including mirrors: 2062 mm
Front track: 1531 mm
Rear (Back) track: 1538 mm
Front overhang: 880 mm
Rear overhang: 993 mm
Ride height (ground clearance): 140 mm
Minimum turning circle (turning diameter): 12.2 m
Powertrain, Suspension and Brakes:
Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels of the vehicle.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 5 gears, manual transmission
Front brakes: Ventilated discs
Rear brakes: Disc
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Electric Steering
Tires size: 205/55 R16
Wheel rims size: 6J x 16
Front suspension: Independent, type McPherson with coil Spring and anti-roll bar
Rear suspension: Rigid axle suspension, Transverse stabilizer, Leaf Spring
