Everything you need to know about specifications and performance - Volkswagen Caravelle 1987 - 1.6 TD (70 Hp) Syncro 16
Overview:
What is the engine capacity of a Volkswagen Caravelle 1987?
The engine capacity of the Volkswagen Caravelle 1987 is 1588.
Volkswagen Caravelle 1987 How many horsepower?
The engine power of the Volkswagen Caravelle 1987 is 70 Hp @ 4500 rpm..
What is the Volkswagen Caravelle 1987 engine?
Volkswagen Caravelle 1987 engine is JX. (Click to see other cars using the same engine)
General:
Brand: Volkswagen
Model: Caravelle
Generation: T3
Modification (Engine): 1.6 TD (70 Hp) Syncro 16
Start of production: 1987
End of production: 1992
Powertrain Architecture: Internal Combustion Engine
Body type: Van
Seats: 7-9
Doors: 4-5
Engine:
Power: 70 hp @ 4500 rpm.
Power per litre: 44.1 hp/l
Torque: 138 nm @ 2500 rpm.
Engine Model/Code:JX
Engine displacement: 1588
Number of cylinders: 4
Engine configuration: Inline
Number of valves per cylinder: 2
Fuel injection system: Precombustion chamber injection
Engine aspiration: Turbocharger
Valvetrain: SOHC
Engine oil capacity: 4.5 l
Coolant: 16 l
Engine layout: Rear, Longitudinal
Cylinder Bore: 76.5 mm
Piston Stroke: 86.4 mm
Compression ratio: 23:1
Performance:
Fuel Type: Diesel
Fuel consumption (economy) - urban: 9.5 l/100 km
Fuel consumption (economy) - extra urban: 9.5 l/100 km
Maximum speed: 116 km/h
Weight-to-power ratio: 24.1 kg/Hp, 41.4 Hp/tonne
Weight-to-torque ratio: 12.2 kg/Nm, 81.7 Nm/tonne
Space:
Kerb Weight (kg): 1690-1720
Max. weight (kg): 2500
Max. roof load: 100 kg
Max load (kg): 780-810
Trunk (boot) space - maximum: 2930 l
Trunk (boot) space - minimum: 1700 l
Permitted trailer load with brakes (12%): 1500 kg
Fuel tank capacity: 70 l
Permitted trailer load without brakes: 600 kg
Permitted towbar download: 75 kg
dimensions:
Ramp-over (brakeover) angle: 29°
Wading depth: 390 mm
Length: 4600 mm
Width: 1845 mm
Height: 2020-2028 mm
wheelbase: 2480 mm
Front track: 1597 mm
Rear (Back) track: 1590 mm
Front overhang: 1175 mm
Rear overhang: 925 mm
Ride height (ground clearance): 218-226 mm
Minimum turning circle (turning diameter): 11.3 m
Approach angle: 24°
Departure angle: 24°
Climb angle: 32°
Powertrain, Suspension and Brakes:
Drivetrain Architecture: The Internal combustion Engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel: All wheel drive (4x4)
Number of gears and type of gearbox: 5 gears, manual transmission
Front brakes: Disc
Rear brakes: Drum
Steering type: Steering rack and pinion
Tires size: 195/80 R16; 205/80 R16
Wheel rims size: 5.5J x 16
Front suspension: Coil spring, Double wishbone, Transverse stabilizer
Rear suspension: Independent coil spring, Trailing arm
