Hyundai Elantra IV 1.6 CRDi (85 Hp)
Overall Rating
Hyundai Elantra:
The Hyundai Elantra , also known as the Hyundai Avante , is a series of compact cars produced by the South Korean manufacturer Hyundai since 1990.
In South Korea, the first-generation model was initially sold under the "Elantra" nameplate, but starting from the second-generation, Korean models were sold under the "Avante" nameplate, with the "Elantra" name continue to be used on export models. The "Avante" name is not used in most export markets due to its similarity with Audi's "Avant" designation, used for their station wagon models. As of 2018, Singapore is the only export market outside South Korea to utilize the "Avante" name....(Read more on Wikipedia)
IV Overview:
Hyundai Elantra (IV). With 255 Nm of torque, it offers ample pulling power. Weighing only 1259 kg, it’s quite light. Front‑wheel drive delivers efficiency and easy handling. Acceleration is relatively slow (0–100 km/h in 12.1 s). The top speed reaches 184 km/h. A four-door car with a separate trunk, ideal for families and daily commuting. Seating for 5 makes it ideal for daily use.
The Hyundai Elantra IV (HD) was not tested by Euro NCAP. Other regional tests (like ANCAP) indicated a reasonable safety performance for its class and era.
1.6 CRDi (85 Hp) Verdict:
Performance Verdict
The 85 Hp 1.6 CRDi engine is primarily focused on economy, offering modest acceleration. Its strong low-end torque makes it feel capable in city traffic despite the lower horsepower.
Fuel Economy
This diesel engine is the most fuel-efficient option in the lineup, delivering excellent MPG figures, especially on longer journeys.
Pros and Cons:
Pros:
- • Spacious and comfortable interior for its class
- • Good value for money with generous standard features
- • Reputable Hyundai reliability and low running costs
- • Smooth ride quality suitable for daily commuting
- • Efficient engine options, especially the diesel
Cons:
- • Uninspired driving dynamics; not particularly engaging
- • Automatic transmission can feel sluggish and dated
- • Interior materials, while durable, lack premium feel
- • Exterior design is somewhat conservative
- • Limited advanced safety features compared to modern cars
Specifications:
Specifications are compared to those of the previous generation(III: 2003 - 2006).
| General: | |
|---|---|
| Brand: | Hyundai |
| Model: | Elantra |
| Generation: | IV |
| Modification (Engine): | 1.6 CRDi (85 Hp) |
| Start of production: | 2006 |
| End of production: | 2011 |
| Powertrain Architecture: | Internal Combustion engine |
| Body type: | Sedan |
| Seats: | 5 |
| Doors: | 4 |
| Engine: | |
|---|---|
| Power: | 85 Hp @ 4000 rpm. Same horsepower |
| Power per litre: | 53.7 Hp/l [10mm more] |
| Torque: | 255 Nm @ 1900-2750 rpm. |
| Engine Model/Code: | D4FB More details about the engine D4FB |
| Engine displacement: | 1582 |
| Number of cylinders: | 4 |
| Engine configuration: | Inline |
| Fuel injection system: | Diesel Commonrail |
| Engine aspiration: | Turbocharger, Intercooler |
| Engine oil capacity: | 5.3 l |
| Coolant: | 6.8 l |
| Engine layout: | Front, Transverse |
| Cylinder Bore: | 77.2 mm |
| Piston Stroke: | 84.5 mm |
| Compression ratio: | 17.3:1 |
| Performance: | |
|---|---|
| Fuel Type: | Diesel |
| Acceleration 0 - 100 km/h: | 12.1 sec |
| Acceleration 0 - 62 mph: | 12.1 sec |
| Maximum speed: | 184 km/h |
| Weight-to-power ratio: | 14.8 kg/Hp, 67.5 Hp/tonne |
| Weight-to-torque ratio: | 4.9 kg/Nm, 202.5 Nm/tonne |
| Acceleration 0 - 60 mph: | 11.5 sec |
| Space: | |
|---|---|
| Kerb Weight: | 1259 |
| Max. weight: | 1770 |
| Max load: | 511 |
| Trunk (boot) space - minimum: | 460 l |
| Fuel tank capacity: | 53 l |
| Size: | |
|---|---|
| Length: | 4505 mm [10mm more] |
| Width: | 1775 mm [55mm more] |
| Height: | 1490 mm [65mm more] |
| Wheelbase: | 2690 mm [80mm more] |
| Front track: | 1543 mm |
| Rear (Back) track: | 1541 mm |
| Minimum turning circle (turning diameter): | 11.3 m [above average] |
| Powertrain: | |
|---|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears | 5 |
| Transmission type | Manual |
| Front brakes | Ventilated discs [Best for performance and cooling.] |
| Rear brakes | Drum [bad for performance and cooling.] |
| Steering type | Steering rack and pinion |
| Tires size | 185/65 R15 |
| Wheel rims size | 5.5J X 15 |
| Front suspension | Spring Strut |
| Rear suspension | Transverse stabilizer |
