Everything you need to know about specifications and performance - Toyota RAV4 2012 - 50 kWh (154 Hp)
Overview:
How powerful is the electrical system in the Toyota RAV4 2012?
The power of the electrical system in the Toyota RAV4 2012 is 154 Hp hp.
General:
Brand: Toyota
Model: RAV4
Generation: EV II (QEA38)
Modification (Engine): 50 kWh (154 Hp)
Start of production: May, 2012
End of production: 2014
Powertrain Architecture: BEV (Electric Vehicle)
Body type:Sports Utility Vehicle (SUV)
Seats: 5
Doors: 5
Engine:
Performance:
Fuel Type: Electricity
Emission standard: ZEV
Maximum speed: 160 km/h
Weight-to-power ratio: 11.9 kg/Hp, 84.2 Hp/tonne
Weight-to-torque ratio: 4.9 kg/Nm, 202.3 Nm/tonne
Acceleration 0 - 60 mph: 7 sec
Electric system:
Net (usable) battery capacity: 41.8 kWh
Gross battery capacity: 50 kWh
Battery technology: Lithium-ion (Li-Ion)
Battery location: Below the floor
System power: 154 hp
System torque: 370 nm
All-electric range: 166 km
Electric motor power: 154 hp
Electric motor Torque: 370 nm
Average Energy consumption: 27.6 kWh/100 km
Electric motor location: Front axle, Transverse
Battery weight: 384 kg
Battery voltage: 386 V
Space:
Kerb Weight (kg): 1829
Max. weight (kg): 2270
Max load (kg): 441
Trunk (boot) space - maximum: 2067 l
Trunk (boot) space - minimum: 1031 l
dimensions:
Length: 4575 mm
Width: 1816 mm
Height: 1684 mm
wheelbase: 2659 mm
Front track: 1560 mm
Rear (Back) track: 1560 mm
Ride height (ground clearance): 150 mm
Minimum turning circle (turning diameter): 10.6 m
Powertrain, Suspension and Brakes:
Drivetrain Architecture: One electric motor drives the front wheels.
Drive wheel: Front wheel drive
Number of gears and type of gearbox: 1 gears, automatic transmission
Front brakes: Ventilated discs
Rear brakes: Disc
Assisting systems: ABS (Anti-lock braking system)
Steering type: Steering rack and pinion
Power steering: Electric Steering
Tires size: 225/65 R17
Wheel rims size: 7J x 17
Front suspension: Independent type McPherson, Transverse stabilizer
Rear suspension: Double wishbone, Transverse stabilizer, Trailing arm, Coil Spring
