Everything you need to know about specifications and performance - Volkswagen Caravelle 2015 - 2.0 TDI (204 Hp) 4MOTION

Full specifications and technical details 2015 Volkswagen Caravelle (T6) 2.0 TDI (204 Hp) 4MOTION

Overview:

What is the engine capacity of a Volkswagen Caravelle 2015?
The engine capacity of the Volkswagen Caravelle 2015 is 1968.

Volkswagen Caravelle 2015 How many horsepower?
The engine power of the Volkswagen Caravelle 2015 is 204 Hp @ 4000 rpm..

What is the Volkswagen Caravelle 2015 engine?
Volkswagen Caravelle 2015 engine is EA288 / CXEB. (Click to see other cars using the same engine)

How much gasoline does a Volkswagen Caravelle 2015 consume?
The Volkswagen Caravelle 2015 consumes 6.6-6.7 liters of gasoline per 100 km

General:

Brand: Volkswagen

Model: Caravelle

Generation: T6

Modification (Engine): 2.0 TDI (204 Hp) 4MOTION

Start of production: 2015

End of production: 2018

Powertrain Architecture: Internal Combustion Engine

Body type: Van

Seats: 4-9

Doors: 4-5

Engine:

Engine systems: Start & Stop System

Power: 204 hp @ 4000 rpm.

Power per litre: 103.7 hp/l

Torque: 450 nm @ 1400-2400 rpm.

Engine Model/Code:EA288 / CXEB

Engine displacement: 1968

Number of cylinders: 4

Engine configuration: Inline

Number of valves per cylinder: 4

Fuel injection system: Diesel Commonrail

Engine aspiration: BiTurbo, Intercooler

Valvetrain: DOHC

Engine oil capacity: 7.4 l

Engine layout: Front, Transverse

Cylinder Bore: 81 mm

Piston Stroke: 95.5 mm

Compression ratio: 15.5:1

Performance:

Fuel Type: Diesel

Fuel consumption (economy) - urban: 7.7-7.8 l/100 km

Fuel consumption (economy) - extra urban: 6-6.1 l/100 km

Fuel consumption (economy) - combined (NEDC): 6.6-6.7 l/100 km

Fuel consumption (economy) - urban (NEDC): 7.7-7.8 l/100 km

Fuel consumption (economy) - extra urban (NEDC): 6-6.1 l/100 km

Fuel consumption (economy) - combined: 6.6-6.7 l/100 km

Emission standard: Euro 6

Acceleration 0 - 100 km/h: 9.3 sec

Acceleration 0 - 62 mph: 9.3 sec

Maximum speed: 199 km/h

Weight-to-power ratio: 9.6 kg/Hp, 104.3 Hp/tonne

Weight-to-torque ratio: 4.3 kg/Nm, 230.2 Nm/tonne

Acceleration 0 - 60 mph: 8.8 sec

Space:

Kerb Weight (kg): 1955-2405

Max. weight (kg): 3080-3200

Max. roof load: 100 kg

Max load (kg): 795-1125

Trunk (boot) space - maximum: 5800 l

Permitted trailer load with brakes (12%): 2500 kg

Fuel tank capacity: 70 l

AdBlue tank: 13 l

Permitted trailer load without brakes: 750 kg

Permitted towbar download: 100 kg

dimensions:

Ramp-over (brakeover) angle: 13.7°

Length: 4904 mm

Width: 1904 mm

Height: 1970-1990 mm

wheelbase: 3000 mm

Width including mirrors: 2297 mm

Front overhang: 908 mm

Rear overhang: 993 mm

Ride height (ground clearance): 193-201 mm

Minimum turning circle (turning diameter): 11.9 m

Approach angle: 21.2°

Departure angle: 16.2°

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.

Drive wheel: All wheel drive (4x4)

Number of gears and type of gearbox: 6 gears, manual transmission

Front brakes: Ventilated discs, 340x32.5 mm

Rear brakes: Ventilated discs, 294x22 mm

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Power steering: Hydraulic Steering

Tires size: 215/60 R17; 215/65 R17; 235/55 R17; 255/45 R18

Wheel rims size: 7J x 17; 8J x 18

Front suspension: Independent, type McPherson with coil Spring and anti-roll bar

Rear suspension: Independent coil spring, Wishbone, Transverse stabilizer
