Everything you need to know about specifications and performance - Subaru Crosstrek 2024 - 2.0ie (136 Hp) Mild Hybrid AWD Lineartronic

Full specifications and technical details 2024 Subaru Crosstrek III 2.0ie (136 Hp) Mild Hybrid AWD Lineartronic

Overview:

What is the engine capacity of a Subaru Crosstrek 2024?
The engine capacity of the Subaru Crosstrek 2024 is 1995.

Subaru Crosstrek 2024 How many horsepower?
The engine power of the Subaru Crosstrek 2024 is 136 Hp @ 5600 rpm..

What is the Subaru Crosstrek 2024 engine?
Subaru Crosstrek 2024 engine is FB20. (Click to see other cars using the same engine)

What is the recommended oil for a Subaru Crosstrek 2024 engine?
The recommended oil for a Subaru Crosstrek 2024 car engine is 0W-20.

What type of camshaft transmission system is used in a Subaru Crosstrek 2024 engine?
chain is used to transmit motion.

General:

Brand: Subaru

Model: Crosstrek

Generation: III

Modification (Engine): 2.0ie (136 Hp) Mild Hybrid AWD Lineartronic

Start of production: January, 2024

End of production:

Powertrain Architecture:MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV)

Body type: SUV, Crossover

Seats: 5

Doors: 5

Engine:

Engine systems: Start & Stop System

Power: 136 hp @ 5600 rpm.

Power per litre: 68.2 hp/l

Torque: 182 nm @ 4000 rpm.

Engine Model/Code:FB20

Engine displacement: 1995

Number of cylinders: 4

Engine configuration: Boxer

Number of valves per cylinder: 4

Fuel injection system: Direct injection

Engine aspiration: Naturally aspirated Engine

Engine layout: Front, Longitudinal

Cylinder Bore: 84 mm

Piston Stroke: 90 mm

Compression ratio: 12.5:1

recommended engine oil: 0W-20

euro standards: EURO 5/6

engine lifespan (km): ~250 000

weight (kg): 135 (FB20B)
140 (FB20D)
175 (FB20X)

timing drive: chain

Show more details about this engine

Performance:

Fuel Type: Petrol (Gasoline)

Combined fuel consumption (WLTP): 7.7 l/100 km

Fuel consumption at Low speed (WLTP): 8 l/100 km

Fuel consumption at Medium speed (WLTP): 7.4 l/100 km

Fuel consumption at high speed (WLTP): 6.7 l/100 km

Fuel consumption at very high speed (WLTP): 8.6 l/100 km

Emission standard: Euro 6d-ISC-Fcm

Acceleration 0 - 100 km/h: 10.8 sec

Acceleration 0 - 62 mph: 10.8 sec

Maximum speed: 198 km/h

Weight-to-power ratio: 11.2 kg/Hp, 89.5 Hp/tonne

Weight-to-torque ratio: 8.4 kg/Nm, 119.7 Nm/tonne

Acceleration 0 - 60 mph: 10.3 sec

Electric system:

Battery technology: Lithium-ion (Li-Ion)

Electric motor power: 17 hp

Electric motor Torque: 66 nm

Electric motor location: Integrated into the transmission

Electric motor type: Synchronous

Battery voltage: 118.4 V

Space:

Kerb Weight (kg): 1520-1553

Max. weight (kg): 2100

Max. roof load: 80 kg

Max load (kg): 547-580

Trunk (boot) space - minimum: 315 l

Permitted trailer load with brakes (12%): 1270 kg

Fuel tank capacity: 48 l

Permitted trailer load without brakes: 750 kg

Permitted towbar download: 80 kg

dimensions:

Ramp-over (brakeover) angle: 20.8°

Length: 4495 mm

Width: 1800 mm

Height: 1600 mm

wheelbase: 2670 mm

Width including mirrors: 2018 mm

Front track: 1555 mm

Rear (Back) track: 1555 mm

Ride height (ground clearance): 220 mm

Minimum turning circle (turning diameter): 11.8 m

Approach angle: 19.3°

Departure angle: 31.2-31.3°

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work only in mixed mode.

Drive wheel: All wheel drive (4x4)

Number of gears and type of gearbox: automatic transmission Lineartronic CVT

Front brakes: Ventilated discs

Rear brakes: Ventilated discs

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Power steering: Electric Steering

Tires size: 225/60 R17; 225/55 R18

Wheel rims size: 7J x 17; 7J x 18
