Everything you need to know about specifications and performance - Toyota Camry 2011 - 2.5 (200 Hp) Hybrid e-CVT

Full specifications and technical details 2011 Toyota Camry VII (XV50) 2.5 (200 Hp) Hybrid e-CVT

Overview:

What is the engine capacity of a Toyota Camry 2011?
The engine capacity of the Toyota Camry 2011 is 2494.

Toyota Camry 2011 How many horsepower?
The engine power of the Toyota Camry 2011 is 156 Hp @ 5700 rpm..

What is the Toyota Camry 2011 engine?
Toyota Camry 2011 engine is 2AR-FXE. (Click to see other cars using the same engine)

How powerful is the electrical system in the Toyota Camry 2011?
The power of the electrical system in the Toyota Camry 2011 is 200 Hp hp.

How much gasoline does a Toyota Camry 2011 consume?
The Toyota Camry 2011 consumes 5.7 liters of gasoline per 100 km

What is the recommended oil for a Toyota Camry 2011 engine?
The recommended oil for a Toyota Camry 2011 car engine is 5W-30.

What type of camshaft transmission system is used in a Toyota Camry 2011 engine?
chain is used to transmit motion.

General:

Brand: Toyota

Model: Camry

Generation: VII (XV50)

Modification (Engine): 2.5 (200 Hp) Hybrid e-CVT

Start of production: 2011

End of production: 2014

Powertrain Architecture: FHEV (Full Hybrid Electric Vehicle)

Body type:Sedan

Seats: 5

Doors: 4

Engine:

Power: 156 hp @ 5700 rpm.

Power per litre: 62.6 hp/l

Torque: 212 nm @ 4500 rpm.

Engine Model/Code:2AR-FXE

Engine displacement: 2494

Number of cylinders: 4

Engine configuration: Inline

Number of valves per cylinder: 4

Fuel injection system: Multi-port manifold injection

Engine aspiration: Naturally aspirated Engine

Valvetrain: DOHC, Dual VVT-i

Engine oil capacity: 4.4 l

Coolant: 7.2 l

Engine layout: Front, Transverse

Cylinder Bore: 90 mm

Piston Stroke: 98 mm

Compression ratio: 10.4:1

recommended engine oil: 5W-30

euro standards: EURO 5

engine lifespan (km): ~300 000

weight (kg): 149

timing drive: chain

Show more details about this engine

Performance:

Fuel Type: Petrol (Gasoline)

Fuel consumption (economy) - urban: 5.4 l/100 km

Fuel consumption (economy) - extra urban: 6 l/100 km

Fuel consumption (economy) - combined: 5.7 l/100 km

Weight-to-power ratio: 7.8 kg/Hp, 128.4 Hp/tonne

Weight-to-torque ratio: 7.3 kg/Nm, 136.1 Nm/tonne

Electric system:

Battery technology: Nickel-metal hydride (NiMH)

Battery location: Behind the back wall of the passenger cabin

System power: 200 hp

Electric motor power: 143 hp

Electric motor Torque: 270 nm

Electric motor location: Integrated into the transmission

Electric motor type: Synchronous

Battery voltage: 244.8 V

Space:

Kerb Weight (kg): 1558

Trunk (boot) space - minimum: 371 l

Fuel tank capacity: 64 l

dimensions:

Length: 4806 mm

Width: 1821 mm

Height: 1470 mm

wheelbase: 2776 mm

Front track: 1585 mm

Rear (Back) track: 1575 mm

Ride height (ground clearance): 155 mm

Minimum turning circle (turning diameter): 11.1 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode.

Drive wheel: Front wheel drive

Number of gears and type of gearbox: automatic transmission e-CVT

Front brakes: Ventilated discs

Rear brakes: Disc

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Power steering: Electric Steering

Tires size: 205/65 R16

Wheel rims size: 6.5J x 16

Front suspension: Independent, type McPherson with coil Spring and anti-roll bar

Rear suspension: Independent multi-link Spring suspension with stabilizer
