Volkswagen Passat Variant (B5) 1.8 20V (125 Hp) Automatic
Overall Rating
Volkswagen Passat:
The Volkswagen Passat is a nameplate of large family cars manufactured and marketed by the German automobile manufacturer Volkswagen since 1973 and also marketed variously as the Dasher, Santana, Quantum, Magotan, Corsar and Carat — in saloon, estate, and hatchback body styles.
A "four-door coupé" variant of the Passat with a lower roof was released in the North American market in 2008 as the Passat CC, which was then renamed to Volkswagen CC. The CC was succeeded by the Arteon in 2017....(Read more on Wikipedia)
Variant (B5) Overview:
Volkswagen Passat (Variant (B5)). With 168 Nm of torque, it offers ample pulling power. With a weight of 1315 kg, it falls in the mid‑range. Front‑wheel drive delivers efficiency and easy handling. Acceleration is relatively slow (0–100 km/h in 12.9 s). The top speed reaches 195 km/h. A car with an extended rear cargo area, combining passenger comfort with increased storage. Seating for 5 makes it ideal for daily use.
1.8 20V (125 Hp) Automatic Verdict:
Performance Verdict
Offers adequate performance for daily driving, but the automatic transmission combined with 125 hp can feel sluggish, especially when loaded.
Fuel Economy
Moderate fuel consumption for its size, but the automatic can slightly increase thirst compared to manual versions.
Pros and Cons:
Pros:
- • Excellent build quality and refined interior for its class.
- • Wide range of efficient and powerful engines, especially the 1.9 TDI.
- • Comfortable ride quality, ideal for long journeys.
- • Spacious interior and large boot capacity in Variant form.
- • Timeless design that still looks good today.
Cons:
- • Some engines (e.g., early 1.8T, 2.5 TDI) can have known reliability issues.
- • Front suspension components (multi-link) are prone to wear.
- • Can be expensive to maintain if not properly looked after.
- • Entry-level petrol engines are underpowered for the car's size.
- • Automatic transmissions can be less engaging and less economical.
Specifications:
Specifications are compared to those of the previous generation(B4: 1996 - 1996).
| General: | |
|---|---|
| Brand: | Volkswagen |
| Model: | Passat |
| Generation: | Variant (B5) |
| Modification (Engine): | 1.8 20V (125 Hp) Automatic |
| Start of production: | 1997 |
| End of production: | 2000 |
| Powertrain Architecture: | Internal Combustion engine |
| Body type: | Station wagon (estate) |
| Seats: | 5 |
| Doors: | 5 |
| Engine: | |
|---|---|
| Power: | 125 Hp @ 5800 rpm. Same horsepower |
| Power per litre: | 70.2 Hp/l [70mm more] |
| Torque: | 168 Nm @ 3500 rpm. |
| Engine Model/Code: | ADR, APT, ARG More details about the engine ADR, APT, ARG |
| Engine displacement: | 1781 |
| Number of cylinders: | 4 |
| Engine configuration: | Inline |
| Number of valves per cylinder: | 5 |
| Fuel injection system: | Multi-port manifold injection |
| Engine aspiration: | Naturally aspirated engine |
| Valvetrain: | DOHC |
| Engine oil capacity: | 3.5 l |
| Coolant: | 7 l |
| Engine layout: | Front, Longitudinal |
| Cylinder Bore: | 81 mm |
| Piston Stroke: | 86.4 mm |
| Compression ratio: | 10.3:1 |
| Performance: | |
|---|---|
| Fuel Type: | Petrol (Gasoline) |
| Fuel consumption (economy) - urban: | 12.4 l/100 km |
| Fuel consumption (economy) - extra urban: | 7.2 l/100 km |
| Acceleration 0 - 100 km/h: | 12.9 sec |
| Acceleration 0 - 62 mph: | 12.9 sec |
| Maximum speed: | 195 km/h |
| Weight-to-power ratio: | 10.5 kg/Hp, 95.1 Hp/tonne |
| Weight-to-torque ratio: | 7.8 kg/Nm, 127.8 Nm/tonne |
| Acceleration 0 - 60 mph: | 12.3 sec |
| Space: | |
|---|---|
| Kerb Weight: | 1315 |
| Max. weight: | 1865 |
| Max load: | 550 |
| Trunk (boot) space - maximum: | 1600 l |
| Trunk (boot) space - minimum: | 495 l |
| Fuel tank capacity: | 62 l |
| Size: | |
|---|---|
| Length: | 4675 mm [70mm more] |
| Width: | 1740 mm [20mm more] |
| Height: | 1459 mm [29mm more] |
| Wheelbase: | 2703 mm [78mm more] |
| Front track: | 1498 mm |
| Rear (Back) track: | 1500 mm |
| Powertrain: | |
|---|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears | 4 |
| Transmission type | Automatic |
| Front brakes | Ventilated discs [Best for performance and cooling.] |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 195/65 R15 |
| Wheel rims size | 6J x 15 |
| Front suspension | Coil spring |
| Rear suspension | Coil spring |
