Volkswagen Passat Variant (B5) 1.9 TDI (130 Hp)
Overall Rating
Volkswagen Passat:
The Volkswagen Passat is a nameplate of large family cars manufactured and marketed by the German automobile manufacturer Volkswagen since 1973 and also marketed variously as the Dasher, Santana, Quantum, Magotan, Corsar and Carat — in saloon, estate, and hatchback body styles.
A "four-door coupé" variant of the Passat with a lower roof was released in the North American market in 2008 as the Passat CC, which was then renamed to Volkswagen CC. The CC was succeeded by the Arteon in 2017....(Read more on Wikipedia)
Variant (B5) Overview:
Volkswagen Passat (Variant (B5)). With 310 Nm of torque, it offers ample pulling power. It has moderate fuel consumption (~7.6 l/100km). With a weight of 1445 kg, it falls in the mid‑range. Front‑wheel drive delivers efficiency and easy handling. Acceleration is relatively slow (0–100 km/h in 10.2 s). The top speed reaches 201 km/h. A car with an extended rear cargo area, combining passenger comfort with increased storage. Seating for 5 makes it ideal for daily use.
1.9 TDI (130 Hp) Verdict:
Performance Verdict
An excellent all-rounder, offering a significant boost in power and torque over earlier 1.9 TDIs, providing strong, effortless acceleration and superb cruising ability.
Fuel Economy
Outstanding fuel economy, combining strong performance with very low running costs, making it a highly desirable option.
Pros and Cons:
Pros:
- • Excellent build quality and refined interior for its class.
- • Wide range of efficient and powerful engines, especially the 1.9 TDI.
- • Comfortable ride quality, ideal for long journeys.
- • Spacious interior and large boot capacity in Variant form.
- • Timeless design that still looks good today.
Cons:
- • Some engines (e.g., early 1.8T, 2.5 TDI) can have known reliability issues.
- • Front suspension components (multi-link) are prone to wear.
- • Can be expensive to maintain if not properly looked after.
- • Entry-level petrol engines are underpowered for the car's size.
- • Automatic transmissions can be less engaging and less economical.
Specifications:
Specifications are compared to those of the previous generation(Variant (B5): 1998 - 2000).
| General: | |
|---|---|
| Brand: | Volkswagen |
| Model: | Passat |
| Generation: | Variant (B5) |
| Modification (Engine): | 1.9 TDI (130 Hp) |
| Start of production: | 1999 |
| End of production: | 2000 |
| Powertrain Architecture: | Internal Combustion engine |
| Body type: | Station wagon (estate) |
| Seats: | 5 |
| Doors: | 5 |
| Engine: | |
|---|---|
| Power: | 130 Hp @ 4000 rpm. Same horsepower |
| Power per litre: | 68.6 Hp/l [Same length.] |
| Torque: | 310 Nm @ 1900 rpm. |
| Engine Model/Code: | AVF, AWX More details about the engine AVF, AWX |
| Engine displacement: | 1896 |
| Number of cylinders: | 4 |
| Engine configuration: | Inline |
| Number of valves per cylinder: | 2 |
| Fuel injection system: | Pump-nozzle (Unit Injector) |
| Engine aspiration: | Turbocharger, Intercooler |
| Valvetrain: | OHC |
| Engine oil capacity: | 4 l |
| Coolant: | 7 l |
| Engine layout: | Front, Longitudinal |
| Cylinder Bore: | 79.5 mm |
| Piston Stroke: | 95.5 mm |
| Compression ratio: | 19:1 |
| Performance: | |
|---|---|
| Fuel Type: | Diesel |
| Fuel consumption (economy) - urban: | 7.6 l/100 km |
| Fuel consumption (economy) - extra urban: | 4.7 l/100 km |
| Acceleration 0 - 100 km/h: | 10.2 sec |
| Acceleration 0 - 62 mph: | 10.2 sec |
| Maximum speed: | 201 km/h |
| Weight-to-power ratio: | 11.1 kg/Hp, 90 Hp/tonne |
| Weight-to-torque ratio: | 4.7 kg/Nm, 214.5 Nm/tonne |
| Acceleration 0 - 60 mph: | 9.7 sec |
| Space: | |
|---|---|
| Kerb Weight: | 1445 |
| Max. weight: | 2010 |
| Max load: | 565 |
| Trunk (boot) space - maximum: | 1600 l |
| Trunk (boot) space - minimum: | 495 l |
| Fuel tank capacity: | 62 l |
| Size: | |
|---|---|
| Length: | 4683 mm [Same length.] |
| Width: | 1746 mm [Same width.] |
| Height: | 1498 mm [Same height.] |
| Wheelbase: | 2703 mm [Same wheelbase.] |
| Front track: | 1515 mm |
| Rear (Back) track: | 1515 mm |
| Powertrain: | |
|---|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
| Drive wheel | Front wheel drive |
| Number of gears | 6 |
| Transmission type | Manual |
| Front brakes | Ventilated discs [Best for performance and cooling.] |
| Rear brakes | Disc |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Hydraulic Steering |
| Tires size | 195/65 R15 |
| Wheel rims size | 6J x 15 |
| Front suspension | Coil spring |
| Rear suspension | Coil spring |
