Everything you need to know about specifications and performance - Volvo V60 2018 - 2.0 T8 TwEn (390 Hp) Plug-in Hybrid AWD Geartronic

Full specifications and technical details 2018 Volvo V60 II 2.0 T8 TwEn (390 Hp) Plug-in Hybrid AWD Geartronic

Overview:

What is the engine capacity of a Volvo V60 2018?
The engine capacity of the Volvo V60 2018 is 1969.

Volvo V60 2018 How many horsepower?
The engine power of the Volvo V60 2018 is 303 Hp @ 6000 rpm..

What is the Volvo V60 2018 engine?
Volvo V60 2018 engine is B4204T34. (Click to see other cars using the same engine)

How powerful is the electrical system in the Volvo V60 2018?
The power of the electrical system in the Volvo V60 2018 is 390 Hp hp.

How much gasoline does a Volvo V60 2018 consume?
The Volvo V60 2018 consumes 1.9-2.1 liters of gasoline per 100 km

General:

Brand: Volvo

Model: V60

Generation: II

Modification (Engine): 2.0 T8 TwEn (390 Hp) Plug-in Hybrid AWD Geartronic

Start of production: October, 2018

End of production: April, 2019

Powertrain Architecture:Plug-In Hybrid Electric Vehicles (PHEVs)

Body type:Station wagon

Seats: 5

Doors: 5

Engine:

Engine systems: Start & Stop System

Power: 303 hp @ 6000 rpm.

Power per litre: 153.9 hp/l

Torque: 400 nm @ 2200-4800 rpm.

Engine Model/Code:B4204T34

Engine displacement: 1969

Number of cylinders: 4

Engine configuration: Inline

Number of valves per cylinder: 4

Fuel injection system: Direct injection

Engine aspiration: turbocharging and Supercharger, Intercooler

Valvetrain: DOHC

Engine oil capacity: 5.6 l

Engine layout: Front, Transverse

Cylinder Bore: 82 mm

Piston Stroke: 93.2 mm

Compression ratio: 10.3:1

Performance:

Fuel Type: Petrol / electricity

Combined fuel consumption (WLTP): 2.1-2.5 l/100 km

Fuel consumption (economy) - combined (NEDC): 1.9-2.1 l/100 km

Fuel consumption (economy) - combined: 1.9-2.1 l/100 km

Emission standard: Euro 6d-TEMP

Acceleration 0 - 100 km/h: 4.9 sec

Acceleration 0 - 62 mph: 4.9 sec

Maximum speed: 250 km/h

Weight-to-power ratio: 5.2 kg/Hp, 193.3 Hp/tonne

Weight-to-torque ratio: 5 kg/Nm, 198.2 Nm/tonne

Max speed (electric): 125 km/h

Acceleration 0 - 60 mph: 4.7 sec

Electric system:

Gross battery capacity: 10.4 kWh

Battery technology: Lithium-ion (Li-Ion)

Battery location: In the central tunnel

System power: 390 hp

All-electric range: 41-46 km

Electric motor power: 87 hp @ 7000 rpm.

Electric motor Torque: 240 nm @ 0-3000 rpm.

Average Energy consumption: 14.3-14.7 kWh/100 km

Electric motor location: Rear axle, Transverse

Average Energy consumption (WLTP): 14.3-14.7 kWh/100 km

All-electric range (WLTP): 41-46 km

Battery voltage: 400 V

Average Energy consumption (NEDC): 14.3-14.8 kWh/100 km

All-electric range (NEDC): 48-49 km

Space:

Kerb Weight (kg): 2018

Max. weight (kg): 2570

Max. roof load: 75 kg

Max load (kg): 552

Trunk (boot) space - maximum: 1441 l

Trunk (boot) space - minimum: 529 l

Permitted trailer load with brakes (12%): 2000 kg

Fuel tank capacity: 60 l

Permitted trailer load without brakes: 750 kg

Permitted towbar download: 100 kg

dimensions:

Length: 4761 mm

Width: 1850 mm

Height: 1427 mm

wheelbase: 2872 mm

Width with mirrors folded: 1916 mm

Width including mirrors: 2040 mm

Front track: 1610 mm

Rear (Back) track: 1610 mm

Front overhang: 848 mm

Rear overhang: 1041 mm

Ride height (ground clearance): 128 mm

Minimum turning circle (turning diameter): 11.3 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) permanently drives the front wheels of the vehicle, the electric motor drives the rear wheels of the vehicle, capable of running in full electric mode, only by the Internal combustion Engine (ICE) or in mixed mode.

Drive wheel: All wheel drive (4x4)

Number of gears and type of gearbox: 8 gears, automatic transmission Geartronic

Front brakes: Ventilated discs, 345x30 mm

Rear brakes: Ventilated discs, 320x20 mm

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Power steering: Electric Steering

Tires size: 235/45 R18; 235/40 R19

Wheel rims size: 8J x 18; 8J x 19

Front suspension: Double wishbone, Transverse stabilizer

Rear suspension: Transverse stabilizer, Leaf Spring
