Everything you need to know about specifications and performance - Volvo V70 2005 - 2.4 D5 (185 Hp) AWD Geartronic

Full specifications and technical details 2005 Volvo V70 II (facelift 2004) 2.4 D5 (185 Hp) AWD Geartronic

Overview:

What is the engine capacity of a Volvo V70 2005?
The engine capacity of the Volvo V70 2005 is 2400.

Volvo V70 2005 How many horsepower?
The engine power of the Volvo V70 2005 is 185 Hp @ 4000 rpm..

What is the Volvo V70 2005 engine?
Volvo V70 2005 engine is D5244T4. (Click to see other cars using the same engine)

How much gasoline does a Volvo V70 2005 consume?
The Volvo V70 2005 consumes 8.3 liters of gasoline per 100 km

What is the recommended oil for a Volvo V70 2005 engine?
The recommended oil for a Volvo V70 2005 car engine is 0W-30.

What type of camshaft transmission system is used in a Volvo V70 2005 engine?
belt is used to transmit motion.

General:

Brand: Volvo

Model: V70

Generation: II (facelift 2004)

Modification (Engine): 2.4 D5 (185 Hp) AWD Geartronic

Start of production: 2005

End of production: 2007

Powertrain Architecture: Internal Combustion Engine

Body type:Station wagon

Seats: 5

Doors: 5

Engine:

Engine systems: Particulate filter

Power: 185 hp @ 4000 rpm.

Power per litre: 77.1 hp/l

Torque: 400 nm @ 2000-2750 rpm.

Engine Model/Code:D5244T4

Engine displacement: 2400

Number of cylinders: 5

Engine configuration: Inline

Number of valves per cylinder: 4

Fuel injection system: Diesel Commonrail

Engine aspiration: Turbocharger, Intercooler

Valvetrain: DOHC

Engine oil capacity: 6.2 l

Engine layout: Front, Transverse

Cylinder Bore: 81 mm

Piston Stroke: 93.15 mm

recommended engine oil: 0W-30

euro standards: EURO 4

engine lifespan (km): ~350 000

timing drive: belt

Show more details about this engine

Performance:

Fuel Type: Diesel

Fuel consumption (economy) - urban: 10.9 l/100 km

Fuel consumption (economy) - extra urban: 6.8 l/100 km

Fuel consumption (economy) - combined (NEDC): 8.3 l/100 km

Fuel consumption (economy) - urban (NEDC): 10.9 l/100 km

Fuel consumption (economy) - extra urban (NEDC): 6.8 l/100 km

Fuel consumption (economy) - combined: 8.3 l/100 km

Emission standard: Euro 4

Acceleration 0 - 100 km/h: 9.5 sec

Acceleration 0 - 62 mph: 9.5 sec

Maximum speed: 210 km/h

Weight-to-power ratio: 9 kg/Hp, 110.9 Hp/tonne

Weight-to-torque ratio: 4.2 kg/Nm, 239.8 Nm/tonne

Acceleration 0 - 60 mph: 9 sec

Space:

Kerb Weight (kg): 1668

Max. weight (kg): 2220

Max. roof load: 100 kg

Max load (kg): 552

Trunk (boot) space - maximum: 1641 l

Trunk (boot) space - minimum: 485 l

Permitted trailer load with brakes (12%): 1800 kg

Fuel tank capacity: 68 l

Permitted trailer load without brakes: 750 kg

Permitted towbar download: 75 kg

Permitted trailer load with brakes (8%): 1950 kg

dimensions:

Length: 4710 mm

Width: 1804 mm

Height: 1490 mm

wheelbase: 2755 mm

Front track: 1551 mm

Rear (Back) track: 1548 mm

Minimum turning circle (turning diameter): 11.9 m

Powertrain, Suspension and Brakes:

Drivetrain Architecture: The Internal combustion Engine (ICE) drives the front wheels permanently, and the rear wheels are driven through an electrically or mechanically operated clutch if necessary.

Drive wheel: All wheel drive (4x4)

Number of gears and type of gearbox: 6 gears, automatic transmission Geartronic

Front brakes: Ventilated discs

Rear brakes: Disc

Assisting systems: ABS (Anti-lock braking system)

Steering type: Steering rack and pinion

Power steering: Hydraulic Steering

Tires size: 205/55 R16

Wheel rims size: 7J x 16

Front suspension: Independent, type McPherson with coil Spring and anti-roll bar

Rear suspension: Independent multi-link suspension, Transverse stabilizer
